Product Details

Single Swinging Metal Door With 15x20 Dual Glazed And Push And Pulls (No Latch)

Type: Acoustical
Perimeter Seal: Single Magnetic Gasket
Bottom Seal: Semi-mortised Automatic
Door Thickness: 1.875" / 47.625mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48" x 96"
STC Rating: 47
Max Fire Rating: N/A

Single Swinging Metal Door With 15x20 Dual Glazed And Push And Pulls (No Latch)

Type: Acoustical
Perimeter Seal: Single Magnetic Gasket
Bottom Seal: Semi-mortised Automatic
Door Thickness: 1.875" / 47.625mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48" x 96"
STC Rating: 47
Max Fire Rating: N/A
Transmission Loss in dB/Hertz - 1/3 Octave Bands
100
30
125
28
160
33
200
32
250
39
315
44
400
44
500
46
630
47
800
44
1000
44
1250
47
1600
50
2000
52
2500
52
3150
51
4000
51
5000
51

Semi-Mortised Door Bottom

A semi-mortised automatic door bottom is always supplied with this assembly. This door bottom allows for a higher undercut. Automatic door bottoms are a good choice when flooring conditions are unknown, as they offer up to a 3/4" undercut.

Single Magnetic Perimeter Seals

This door is equipped with a single Magnetic door sealing system. It consists of a single magnetic perimeter seal. Magnetic seals allow the use of a wide range of electrical hardware, such as electric locks and strikes. Due to their zero preload against the door leaf, the sensitive electronics are not compromised.

UL Fire Ratings

In addition to acoustical testing, Overly has successfully tested this product to the latest UL fire test standard UL10C/UBC 7-2 (positive pressure).

Recommended Hardware:

Hinges:

Heavy WeightANSI A5111 or A8111
5" x 4-1/2"
Suggested Models:
  • Hager BB1168
  • Hager BB1199
  • McKinney T4A3786
  • McKinney T4A3386
  • Stanley FBB168
  • Stanley FBB199

Thresholds:

Saddle
Must have smooth top, no ridges or grooves
Suggested Models:
  • Reese S105
  • Pemko 154
  • NGP 412
  • Zero 164

Pulls:

Surface Mounted
Suggested Models:
  • Rockwood
  • Ives
  • Glynn Johnson

Closers:

Surface MountedANSI 156.4 Grade 1
Suggested Models:
  • Corbin/Russwin DC2000, DC3000, DC4000
  • Dorma 640, 540, 7600, 7800, TS83
  • LCN 4010, 4020, 4041 Super Smoothie
  • Norton 7500, 8500
  • Sargent 250, 251, 350, 351, 1230, 1231, 1250, 1251
