Product Details

Product Catalog
4611215

Single Swinging Flush Metal Door with Push/Pulls (No Latch)

Type: Acoustical
Perimeter Seal: Single Magnetic Gasket
Bottom Seal: Semi-mortised Automatic
Door Thickness: 1.875" / 47.625mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48" x 96"
STC Rating: 46
Max Fire Rating: N/A
4611215

Single Swinging Flush Metal Door with Push/Pulls (No Latch)

Type: Acoustical
Perimeter Seal: Single Magnetic Gasket
Bottom Seal: Semi-mortised Automatic
Door Thickness: 1.875" / 47.625mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48" x 96"
STC Rating: 46
Max Fire Rating: N/A
Transmission Loss in dB/Hertz - 1/3 Octave Bands
100
26
125
30
160
33
200
36
250
39
315
41
400
44
500
44
630
45
800
44
1000
45
1250
46
1600
48
2000
50
2500
49
3150
48
4000
48
5000
49

Semi-Mortised Door Bottom

A semi-mortised automatic door bottom is always supplied with this assembly. This door bottom allows for a higher undercut. Automatic door bottoms are a good choice when flooring conditions are unknown, as they offer up to a 3/4" undercut.

Single Magnetic Perimeter Seals

This door is equipped with a single Magnetic door sealing system. It consists of a single magnetic perimeter seal. Magnetic seals allow the use of a wide range of electrical hardware, such as electric locks and strikes. Due to their zero preload against the door leaf, the sensitive electronics are not compromised.

UL Fire Ratings

In addition to acoustical testing, Overly has successfully tested this product to the latest UL fire test standard UL10C/UBC 7-2 (positive pressure).

Recommended Hardware:

Hinges:

Heavy WeightANSI A5111 or A8111
5" x 4-1/2"
Suggested Models:
  • Hager BB1168
  • Hager BB1199
  • McKinney T4A3786
  • McKinney T4A3386
  • Stanley FBB168
  • Stanley FBB199

Thresholds:

Saddle
Must have smooth top, no ridges or grooves
Suggested Models:
  • Reese S105
  • Pemko 154
  • NGP 412
  • Zero 164

Pulls:

Surface Mounted
Suggested Models:
  • Rockwood
  • Ives
  • Glynn Johnson

Closers:

Surface MountedANSI 156.4 Grade 1
Suggested Models:
  • Corbin/Russwin DC2000, DC3000, DC4000
  • Dorma 640, 540, 7600, 7800, TS83
  • LCN 4010, 4020, 4041 Super Smoothie
  • Norton 7500, 8500
  • Sargent 250, 251, 350, 351, 1230, 1231, 1250, 1251

Support Documents:

Catalogs

Acoustical Products Catalog

CAT-001
Rev: 11
.pdf
Cut Sheets

4611215 Cut Sheet

ENGD-229
Rev: 1
.pdf

Available Sound Control Wall Anchorage Systems For 1-3/4" Thick Metal Acoustical Door With Single Magnetic Perimeter Seals

ENGD-095
Rev: 3
.pdf
Data Sheets

Acoustical Metal Door Data Sheet

SALD-001
Rev: 4
.pdf
Edge Section

1-3/4" Thick Metal Acoustical Door Isolated Edge Construction

DET-001
Rev: 0
.dwg

1-3/4" Thick Metal Acoustical Door Isolated Edge Construction

DET-001
Rev: 0
.pdf
Elevation

Flush Single Door Elevation

DET-041
Rev: 0
.dwg

Flush Single Door Elevation

DET-041
Rev: 0
.pdf
Handing Charts

Handing Chart for Single Swing Door

DET-046
Rev: 0
.pdf

Handing Chart for Single Swing Door

DET-046
Rev: 0
.dwg
Horizontal Section

1-3/4" Thick Single Metal Acoustical Door with Single Magnetic Perimeter Seals, Butt Hinges, & Lock

DET-018
Rev: 0
.dwg

1-3/4" Thick Single Metal Acoustical Door with Single Magnetic Perimeter Seals, Butt Hinges, & Lock

DET-018
Rev: 0
.pdf
Installation Instructions

Installation Instructions for 1-3/4" Acoustical Door Units - Angle Magnetic Seals and Automatic Door Bottoms

SPIIINS0003
Rev: 4
.pdf

Supplemental Installation Instructions for Split-Frame Acoustical Doors - Exposed Fastener

SPIIINS0098
Rev: 0
.pdf

Supplemental Installation Instructions for Split-Frame Acoustical Doors - Hidden Fastener

SPIIINS0099
Rev: 0
.pdf

Supplemental Magnetic Seal Installation Instructions

SPIIINS0053
Rev: 3
.pdf
Sill Section

1-7/8" Thick Doors with Super "H" Door Bottom

DET-114
Rev: 0
.dwg
Specifications

Sound Retardant Swinging Metal Door Assemblies Specification

ENGD-021
Rev: 3
.doc

Sound Retardant Swinging Metal Door Assemblies Specification

ENGD-021
Rev: 3
.pdf
Technical Bulletins

Metal Sound Retardant Door Hardware Information Bulletin

ENGD-018
Rev: 11
.pdf

Required Jamb Openings Widths to Meet ADA Clearance Requirements for 1-3/4", 1-7/8", 2-1/4", 2-1/2", 2-3/4", and 3" Thick Doors

TBD04
Rev: 2
.pdf

Sound Retardant Doors and Windows Monograph

ENGD-038
Rev: 3
.pdf
Test Reports

Acoustical Test Report - STC4611215

TL11-215
Rev: 0
.pdf

Test for compliance to ADA Requirements for Door Openings with Level Swing Hinges

PHY-32473
Rev: 1
.pdf
Vertical Section

1-3/4" Thick Metal Acoustical Door with Single Magnetic Perimeter Seals & Semi-Mortised Automatic Door Bottom

DET-028
Rev: 0
.dwg

1-3/4" Thick Metal Acoustical Door with Single Magnetic Perimeter Seals & Semi-Mortised Automatic Door Bottom

DET-028
Rev: 0
.pdf
Wall Section

Single Magnetic Seals - Bolt In Installation in Existing Poured Concrete Wall or Existing Masonry Wall

DET-066
Rev: 0
.pdf

Single Magnetic Seals - Bolt In Installation in Existing Poured Concrete Wall or Existing Masonry Wall

DET-066
Rev: 0
.dwg

Single Magnetic Seals - Bolt-In Installation In Existing Stud Wall

DET-057
Rev: 0
.pdf

Single Magnetic Seals - Bolt-In Installation In Existing Stud Wall

DET-057
Rev: 0
.dwg

Single Magnetic Seals - Built In Installation In New Masonry Wall

DET-069
Rev: 0
.pdf

Single Magnetic Seals - Built In Installation In New Masonry Wall

DET-069
Rev: 0
.dwg

Single Magnetic Seals - Built In Installation In New Poured Concrete Wall

DET-111
Rev: 0
.pdf

Single Magnetic Seals - Built In Installation In New Poured Concrete Wall

DET-111
Rev: 0
.dwg

Single Magnetic Seals - Built In Installation In New Stud Wall

DET-071
Rev: 0
.dwg

Single Magnetic Seals - Built In Installation In New Stud Wall

DET-071
Rev: 0
.pdf

Single Magnetic Seals - Nailing Clip Installation In New Wood Stud Wall

DET-067
Rev: 0
.pdf

Single Magnetic Seals - Nailing Clip Installation In New Wood Stud Wall

DET-067
Rev: 0
.dwg

Single Magnetic Seals - Optional Split Type Frame For Bolt In Installation In Existing Stud Wall

DET-073
Rev: 1
.pdf

Single Magnetic Seals - Optional Split Type Frame For Bolt In Installation In Existing Stud Wall

DET-073
Rev: 1
.dwg
