Product Details

Single Swinging Flush Metal Door

Type: Acoustical
Perimeter Seal: Double Bubble
Bottom Seal: Semi-mortised Automatic
Door Thickness: 1.875" / 47.625mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48"x96"
STC Rating: 46
Max Fire Rating: 1-1/2 hr

Single Swinging Flush Metal Door

Type: Acoustical
Perimeter Seal: Double Bubble
Bottom Seal: Semi-mortised Automatic
Door Thickness: 1.875" / 47.625mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48"x96"
STC Rating: 46
Max Fire Rating: 1-1/2 hr
Transmission Loss in dB/Hertz - 1/3 Octave Bands
100
26
125
31
160
34
200
37
250
39
315
41
400
44
500
43
630
45
800
43
1000
42
1250
45
1600
50
2000
52
2500
51
3150
49
4000
49
5000
49

Semi-Mortised Door Bottom

A semi-mortised automatic door bottom is always supplied with this assembly. This door bottom allows for a higher undercut. Automatic door bottoms are a good choice when flooring conditions are unknown, as they offer up to a 3/4" undercut.

UL Fire Ratings

In addition to acoustical testing, Overly has successfully tested this product to the latest UL fire test standard UL10C/UBC 7-2 (positive pressure).

Recommended Hardware:

Exit Devices:

MortiseANSI 156.3, Grade 1
Suggested Models:
  • Sargent 8300
  • Von Duprin 9875/9975
RimANSI 156.3, Grade 1
Suggested Models:
  • Sargent 8800
  • Corbin/Russwin ED6200
  • Von Duprin 98/99
Surface Vertical RodANSI A156.3, Grade 1
Suggested Models:
  • Sargent 8700
  • Von Duprin 9927
  • Corbin/Russwin ED6400

Hinges:

Heavy WeightANSI A5111 or A8111
5" x 4-1/2"
Suggested Models:
  • Hager BB1168
  • Hager BB1199
  • McKinney T4A3786
  • McKinney T4A3386
  • Stanley FBB168
  • Stanley FBB199

Thresholds:

Saddle
Must have smooth top, no ridges or grooves
Suggested Models:
  • Reese S105
  • Pemko 154
  • NGP 412
  • Zero 164

Closers:

Surface MountedANSI 156.4 Grade 1
Suggested Models:
  • Corbin/Russwin DC2000, DC3000, DC4000
  • Dorma 640, 540, 7600, 7800, TS83
  • LCN 4010, 4020, 4041 Super Smoothie
  • Norton 7500, 8500
  • Sargent 250, 251, 350, 351, 1230, 1231, 1250, 1251

Support Documents:
