Product Details

Single Swinging Flush Metal Door

Type: Acoustical
Perimeter Seal: Single "H" Gasket
Bottom Seal: Semi-mortised Automatic
Door Thickness: 1.875" / 47.625mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48"x96"
STC Rating: 46
Max Fire Rating: 1-1/2 hr

Single Swinging Flush Metal Door

Type: Acoustical
Perimeter Seal: Single "H" Gasket
Bottom Seal: Semi-mortised Automatic
Door Thickness: 1.875" / 47.625mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48"x96"
STC Rating: 46
Max Fire Rating: 1-1/2 hr
Transmission Loss in dB/Hertz - 1/3 Octave Bands
100
31
125
34
160
39
200
38
250
42
315
47
400
48
500
47
630
47
800
45
1000
41
1250
44
1600
49
2000
53
2500
53
3150
51
4000
52
5000
54

Semi-Mortised Door Bottom

A semi-mortised automatic door bottom is always supplied with this assembly. This door bottom allows for a higher undercut. Automatic door bottoms are a good choice when flooring conditions are unknown, as they offer up to a 3/4" undercut.

Single "H" Perimeter Seals

This door is equipped with our patented single Super "H" door sealing system. It consists of a single compression type perimeter seal, along with a metal retainer and cover. Compression seals typically offer higher acoustical ratings The seal is composed of a felt/neoprene combination that forms a tight perimeter seal.

UL Fire Ratings

In addition to acoustical testing, Overly has successfully tested this product to the latest UL fire test standard UL10C/UBC 7-2 (positive pressure).

Recommended Hardware:

Locks:

CylindricalANSI A156.2, Series 4000 Grade 1
3-3/4" Back-set Required
Suggested Models:
  • Best 94K
  • Schlage "D" Series
  • Sargent 10 Series
  • Corbin/Russwin CL3300
MortiseANSI A156.13 Series 1000 Grade 1
3" maximum rosette diameter
Suggested Models:
  • Best 35H
  • Sargent 8200
  • Schlage "L" Series
  • Corbin / Russwin ML2000

Exit Devices:

MortiseANSI 156.3, Grade 1
3" maximum case width
Suggested Models:
  • Sargent 8300
  • Von Duprin 9875/9975
RimANSI 156.3, Grade 1
Suggested Models:
  • Sargent 8800
  • Corbin/Russwin ED6200
  • Von Duprin 98/99

Hinges:

Heavy WeightANSI A5111 or A8111
5" x 4-1/2"
Suggested Models:
  • Hager BB1168
  • Hager BB1199
  • McKinney T4A3786
  • McKinney T4A3386
  • Stanley FBB168
  • Stanley FBB199

Thresholds:

Saddle
Must have smooth top, no ridges or grooves
Suggested Models:
  • Reese S105
  • Pemko 154
  • NGP 412
  • Zero 164

Closers:

Surface MountedANSI 156.4 Grade 1
Suggested Models:
  • Corbin/Russwin DC2000, DC3000, DC4000
  • Dorma 640, 540, 7600, 7800, TS83
  • LCN 4010, 4020, 4041 Super Smoothie
  • Norton 7500, 8500
  • Sargent 250, 251, 350, 351, 1230, 1231, 1250, 1251
