Single Swinging Wood Door with 15" X 20" Dual Glazed Vision Lite

Type: Acoustical
Perimeter Seal: Double Bubble
Bottom Seal: Raised Threshold
Door Thickness: 1.75" / 44.45mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48" x 120"
STC Rating: 44
Max Fire Rating: 3/4 hr up to 8' height only

Single Swinging Wood Door with 15" X 20" Dual Glazed Vision Lite

Type: Acoustical
Perimeter Seal: Double Bubble
Bottom Seal: Raised Threshold
Door Thickness: 1.75" / 44.45mm
Min Frame Depth: 4.75" / 120.65mm
Max Leaf Size: 48" x 120"
STC Rating: 44
Max Fire Rating: 3/4 hr up to 8' height only
Transmission Loss in dB/Hertz - 1/3 Octave Bands
100
28
125
29
160
32
200
30
250
31
315
37
400
42
500
45
630
46
800
44
1000
42
1250
42
1600
45
2000
46
2500
48
3150
49
4000
51
5000
52

UL Fire Ratings

In addition to acoustical testing, Overly has successfully tested this product to the latest UL fire test standard UL10C/UBC 7-2 (positive pressure).

Recommended Hardware:

Locks:

CylindricalANSI A156.2, Series 4000 Grade 1
3" maximum rose diameter
Suggested Models:
  • Best 94K
  • Schlage "D" Series
  • Sargent 11 Series
  • Corbin/Russwin CL3300
MortiseANSI A156.13 Series 1000 Grade 1
3" maximum rosette diameter
Suggested Models:
  • Best 35H
  • Sargent 8200
  • Schlage "L" Series
  • Corbin / Russwin ML2000

Exit Devices:

MortiseANSI 156.3, Grade 1
Suggested Models:
  • Sargent 8300
  • Von Duprin 9875/9975
RimANSI 156.3, Grade 1
Suggested Models:
  • Sargent 8800
  • Corbin/Russwin ED6200
  • Von Duprin 98/99
Surface Vertical RodANSI A156.3, Grade 1
Suggested Models:
  • Sargent 8700
  • Von Duprin 9927
  • Corbin/Russwin ED6400

Hinges:

Heavy WeightANSI A5111 or A8111
5" x 4-1/2"
Suggested Models:
  • Hager BB1168
  • Hager BB1199
  • McKinney T4A3786
  • McKinney T4A3386
  • Stanley FBB168
  • Stanley FBB199

Closers:

Surface MountedANSI 156.4 Grade 1
Suggested Models:
  • Corbin/Russwin DC2000, DC3000, DC4000
  • Dorma 640, 540, 7600, 7800, TS83
  • LCN 4010, 4020, 4041 Super Smoothie
  • Norton 7500, 8500
  • Sargent 250, 251, 350, 351, 1230, 1231, 1250, 1251
