Product Details

Single Swinging Flush Metal Door

Type: Acoustical
Perimeter Seal: Dual Magnetic Gasket
Bottom Seal: Super "H" Door Bottom
Door Thickness: 2.75" / 69.85mm
Min Frame Depth: 6.25" / 158.75mm
Max Leaf Size: 48" x 120"
STC Rating: 53
Max Fire Rating: 3 hr

Single Swinging Flush Metal Door

Type: Acoustical
Perimeter Seal: Dual Magnetic Gasket
Bottom Seal: Super "H" Door Bottom
Door Thickness: 2.75" / 69.85mm
Min Frame Depth: 6.25" / 158.75mm
Max Leaf Size: 48" x 120"
STC Rating: 53
Max Fire Rating: 3 hr
Transmission Loss in dB/Hertz - 1/3 Octave Bands
100
29
125
32
160
37
200
41
250
44
315
46
400
51
500
53
630
53
800
53
1000
51
1250
53
1600
57
2000
62
2500
65
3150
67
4000
67
5000
65

Dual Magnetic Perimeter Seals

This door is equipped with a dual Magnetic door sealing system. It consists of a dual magnetic perimeter seal. Magnetic seals allow the use of a wide range of electrical hardware, such as electric locks and strikes. Due to their zero preload against the door leaf, the sensitive electronics are not compromised. Dual magnetic seals also offer a very high acoustical rating.

Super "H" Door Bottom

Overly's super "H" door bottom is the only choice for unbeatable sound control. Always used in conjunction with our cam-lift hinges, this door bottom compresses tightly against the floor. We recommend smooth level sealing surfaces for this door bottom. Uneven or abrasive flooring may prematurely wear the door bottom. A smooth raised threshold is recommended when using this door bottom.

UL Fire Ratings

In addition to acoustical testing, Overly has successfully tested this product to the latest UL fire test standard UL10C/UBC 7-2 (positive pressure).

Recommended Hardware:

Locks:

CylindricalANSI A156.2, Series 4000 Grade 1
3" maximum rose diameter
Suggested Models:
  • Best 94K
  • Schlage "D" Series
  • Sargent 11 Series
  • Corbin/Russwin CL3300
MortiseANSI A156.13 Series 1000 Grade 1
2" maximum rosette diameter
Suggested Models:
  • Best 35H
  • Sargent 8200
  • Schlage "L" Series
  • Corbin/Russwin ML2000

Exit Devices:

Narrow MortiseANSI 156.3, Grade 1
2" maximum case width
Suggested Models:
  • Sargent 8300
  • Corbin/Russwin ED7600
  • Von Duprin 5575
RimANSI 156.3, Grade 1
Suggested Models:
  • Sargent 8800
  • Corbin/Russwin ED6200
  • Von Duprin 98/99
Surface Vertical RodANSI A156.3, Grade 1
Suggested Models:
  • Sargent 8700
  • Von Duprin 9927
  • Corbin/Russwin ED6400

Flush-Bolts:

6-3/4" x 1"ANSI 156.16
Suggested Models:
  • Ives 458
  • Rockwood 555

Hinges:

Full Mortise Cam-Lift
Suggested Models:
  • Overly MCL-1000

Thresholds:

Saddle
Must have smooth top, no ridges or grooves
Suggested Models:
  • Reese S105
  • Pemko 154
  • NGP 412
  • Zero 164

Closers:

Surface MountedANSI 156.4 Grade 1
Rigid arms are not recommended.
Suggested Models:
  • Corbin/Russwin DC2000, DC3000, DC4000
  • Dorma 8600, 8900
  • LCN 4010, 4020, 4041 Super Smoothie
  • Norton 7500, 8500
  • Sargent 250, 251, 350, 351, 1230, 1231, 1250, 1251

Support Documents:
